Fabric information

The table contains descriptions of all fabric in the catalogue. The column to the left contains the fabric number which is also stated in the product text. Column two contains the composition, weight and other properties. If the fabric is certified the EN standards are noted.


When the fabrics are tested In the Tranemo Skinsafe system (to IEC 61842-1-1 Open Arc test) according to the layer-on-layer principle, the results are noted together with the fabric numbers of the combined fabrics. For example: IEC 61482-1-1, ELIM: 35 calc/m², ATPV: 40 cal/cm² (811+899+901), shows that fabric 811 (Tera TX) is tested together with fabric 899 (Cantex Terry sweatshirt fabric) and fabric 901 (Merino RX underwear fabric) with a result shown in both ELIM and ATPV figures.

No.

Fabric description

003

100% polyester quilt with polyester wadding, 80 g/m²

004

100% polyester quilt with polyester wadding, 110 g/m²

007

100% polyester mesh

008

100% polyester pile, 350 g/m²

009

100% polyester pile, 540 g/m²

012

100% polyester quilt with polyester wadding, 150 g/m²

050

Cantex Heavy Rib - 58% modacrylic / 36% cotton / 4% elastane / 2% antistatic, 300 g/m²

Inherent Flame Retardant tricot.

EN ISO 14116 Index 3

EN 1149-3

054

Flame Retardant quilt - 45% modacrylic / 35% cotton / 18% polyamide / 2% antistatic with polyester wadding, 80 g/m²

Inherent Flame Retardant fabric with Flame Retardant polyester wadding.

055

Flame Retardant quilt - 45% modacrylic / 35% cotton / 18% polyamide / 2% antistatic with polyester wadding, 120 g/m²

Inherent Flame Retardant fabric with Flame Retardant polyester wadding.

060

Flame Retardant pile - 87% modacrylic / 13% cotton, 320 g/m²

Inherent Flame Retardant pile.

EN ISO 14116 Index 3

112

100% cotton, 175 g/m²

Single jersey with good washing characteristics.

113

55% polyester / 45% cotton, 200 g/m²

Pique in fluorescent colours. Pleasant, shape retaining interlock with cotton lining.

EN ISO 20471

RIS-3279-TOM fluorescent orange certified for UK railways

131

100% cotton, 325 g/m²

Comfortable cotton twill.

150

100% cotton, 375 g/m²

Heavyweight cotton twill. Durable. A prewashed garment minimises future shrinkage.

163

Black & White - 100% polyamide, 200 g/m²

Reinforcement fabric with extra high durability.

191

Graphite - carbon / aramid, 300 g/m²

Inherent Flame Retardant fabric for protection for welding.

EN ISO 11611 class 1

210

HTPA - 100% polyamide, 210 g/m²

Reinforcement fabric with extra high durability.

213

HTPA Dobby - 100% polyamide, 260 g/m²

Reinforcement fabric structured weave with extra high durability.

221

60% cotton / 40% polyester, 200 g/m²

Cotton/polyester twill, with feel of cotton and advantages of polyester for durability and washing characteristics.

240

50% cotton / 50% polyester, 215 g/m²

Shape retaining pique of a pleasant cotton/polyester quality.

260

65% cotton / 35% polyester, 300 g/m²

Sweatshirt quality with brushed lining.

261

65% polyester / 35% cotton, 500 g/m²

Bonded jersey with 100% polyester fleece.

262

45% acrylic / 45% polyester / 10% wool, 400 g/m²

Coarse knit tricot bonded with 100% polyester fleece lining.

264

80% polyester / 20% cotton, 300 g/m²

Sweatshirt quality with ring spun reverse in fluorescent colours.

EN ISO 20471

RIS-3279-TOM fluorescent orange certified for UK railways

282

65% polyester / 35% cotton, 310 g/m²

Canvas/Panama with coarse structure.

283

65% polyester / 35% cotton, 310 g/m²

Canvas/Panama with water repellent impregnation.

303

Beaver nylon - 50% polyamide / 50% cotton, 235 g/m²

Twill with nylon on outside which gives hard wearing and abrasion durability. Water repellent impregnation supplemented with a PU-coated inside that gives protection against the wet.

310

4-way stretch, 50% polyamid / 42% polyester / 8% elastane, 250 g/m²

Twill with stretch function in all directions.

400

65% polyester / 35% cotton, 245 g/m²

Cotton/polyester twill, with high comfort level and excellent washing characteristics. The cloth is durable, highly colour-fast and wrinkle resistant. Quick drying.

428

55% polyester / 45% cotton, 215 g/m²

Tricot. 2-layer jacquard with 3-functions that transports and absorbs moisture while insulating heat.

440

54% cotton / 46% polyester, 260 g/m²

Fluorescent twill with ripstop for enhanced tear strength. Cotton inside for extra high comfort level.

EN ISO 20471

RIS-3279-TOM fluorescent orange certified for UK railways

460

T-TEX - 100% polyester, PU coated, 180 g/m²

Wind and water repellent. Waterproof 5 000 mm.

462

T-TEX One - 100% polyester, PU laminated, 205 g/m²

Wind and water repellent. Waterproof 8000 mm.

Breathability / water vapor resistance

EN 343 class 3:3

EN ISO 20471 for fluorescent colours

463

T-TEX RS - 100% polyester, PU laminated, 205 g/m²

Wind and waterproof according to EN 343 4:4. Waterproof 5000 mm.

Breathability / water vapor resistance 5.6 Pa m²/W.

EN 343 class 4:4

EN ISO 20471 for fluorescent colours

RIS-3279-TOM fluorescent orange certified for UK railways

464

T-TEX Plain - 100% polyester, PU-coated, 200 g/m²

Fluorescent polyester fabric with structured yarn.

465

T-TEX 3L - 100% polyester, PU-laminated, 145 g/m²

Fabric with 3 layer function.

Wind and waterproof according to EN 343 4:4. Waterproof 10 000 mm.

Breathability / water vapor resistance 8.2 Pa m²/W.

EN 343 class 4:4

470

100% polyester, 300 g/m²

3 layer fleece with PU laminate and mesh reverse, wind resistant.

480

92% polyester / 8% elastane, 325 g/m²

Softshell, PU laminated with polyester fleece.

Wind and water repellent. Waterproof 3000 mm.

EN ISO 20471 for fluorescent colours

RIS-3279-TOM fluorescent orange certified for UK railways

481

100% polyester, 330 g/m²

Softshell, PU laminated with polyester fleece.

Wind and water repellent. Waterproof 3000 mm.

500

65% polyester / 35% cotton, 300 g/m²

Cotton/polyester twill, with high comfort level and excellent washing characteristics. The cloth is durable, highly colour-fast and wrinkle resistant. Comfort finish gives a pleasant cotton feel.

510

100% polyester fleece, 220 g/m²

Face side brushed.

511

100% polyester fleece, 280 g/m²

Double brushed.

EN ISO 20471 for fluorescent colours

RIS-3279-TOM fluorescent orange certified for UK railways

515

100% polyester, 215 g/m²

Double diamond quilt

801

Barricader TC - 100% para-aramid, with polymer coating, 545 g/m²

Inherent Flame Retardant reinforcement fabric with good protection against molten metal, convective heat and radiant heat.

EN ISO 11612 A1+A2 B2 C1 E3

EN ISO 11611 class 1

EN 1149-3

803

Barricader EP - 100% para-aramid, 545 g/m²

Inherent Flame Retardant reinforcement fabric with good protection against molten metal splashes.

EN ISO 11612 A1 B1 C1 D3 E3 F1

EN ISO 11611 class 1

IEC 61482-1-2 class 1

EN ISO 20471 for fluorescent colours

804

HTFR Dobby - 39% modacrylic / 28% polyamide / 17% cotton / 15% aramid / 1% antistatic, 295 g/m²

Inherent Flame Retardant reinforcement fabric.

EN ISO 11612 A1 B1 C1 F1

EN ISO 11611 class 1

EN 1149-3

805

FR Mesh – 98% aramid / 2% antistatic, 110 g/m²

Inherent Flame Retardant mesh

EN ISO 14116 index 3

EN 1149-3

811

Tera TX - 45% modacrylic / 35% cotton / 18% polyamide / 2% antistatic, 260 g/m²

Inherent Flame Retardant fabric with pleasant feel. Extra reinforced yarn gives good tear resistance despite low weight.

EN ISO 11612 A1+A2 B1 C1 E1 F1

EN ISO 11611 class 1

IEC 61482-1-2 class 1

IEC 61482-1-2 class 2 (811+898/911)

IEC 61482-1-1, ELIM: 8,1 cal/cm², EBT: 8,7 cal/cm²

IEC 61482-1-1, ELIM: 14 cal/cm², ATPV: 22 cal/cm² (811+901)

IEC 61482-1-1, ELIM: 15 cal/cm², ATPV: 18 cal/cm² (811+911)

IEC 61482-1-1, ELIM: 17 cal/cm², EBT: 20 cal/cm² (811+060)

IEC 61482-1-1, ELIM: 17 cal/cm², ATPV: 25 cal/cm² (811+902)

IEC 61482-1-1, ATPV: 20,9 cal/cm² (811+897)

IEC 61482-1-1, EBT: 21,4 cal/cm² (811+898)

IEC 61482-1-1, ELIM: 35 cal/cm², ATPV: 40 cal/cm² (811+899+901)

IEC 61482-1-1, ELIM: 32 cal/cm², ATPV: 41 cal/cm² (811+902+901)

IEC 61482-1-1, ELIM: 37 cal/cm², ATPV: 47 cal/cm² (811+903+901)

IEC 61482-1-1, EBT: 40,5 cal/cm² (811+899+895)

NFPA 70E, ASTM F1506

LOI 29,8%

EN 1149-3

EN 13034

EN ISO 20471 for fluorescent colours

821

Edge HVO - 50% polyester / 27% modacrylic / 22% cotton / 1% antistatic, 355 g/m²

IInherent Flame Retardant fabric.

EN ISO 11612 A1 B1 C1 D1 E3 F1

EN ISO 11611 class 2

IEC 61482-1-2 class 1

IEC 61482-1-2 class 2 (821+911)

IEC 61482-1-1, ELIM: 7,3 cal/cm², ATPV: 9,4 cal/cm²

LOI 27,5%

EN 1149-3

EN 13034

EN ISO 20471 for fluorescent colours

RIS-3279-TOM fluorescent orange certified for UK railways

822

Edge 350 IR - 45% modacrylic / 33% cotton / 20% polyester / 2% antistatic, PU-laminated, 350 g/m²

Inherent Flame Retardant fabric with PU laminate.

Wind and waterproof according to EN 343 3:3. Waterproof > 8000 mm.

Breathability / water vapor resistance 19.8 Pa m²/W.

EN ISO 11612 A1 B1 C1 E1 F1

EN ISO 11611 class 1

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 9,8 cal/cm²

LOI 29,5%

EN 1149-3

EN 13034

EN ISO 20471 for fluorescent colours

RIS-3279-TOM fluorescent orange certified for UK railways

EN 343, class 3:3

830

Apex 300 - 98% aramid / 2% antistatic, 300 g/m²

Inherent Flame Retardant satin with good Flame Retardant protection, combined with high durability.

EN ISO 11612 A1+A2 B1 C1 F1

EN ISO 11611 class 1

IEC 61482-1-2 class 1

IEC 61482-1-1, ELIM: 9,4 cal/cm², ATPV: 12 cal/cm²

LOI 28%

EN 1149-3

EN 13034

832

Apex 220 – 98% aramid / 2% antistatic, 220 g/m²

Inherent Flame Retardant twill.

EN ISO 11612 A1 B1 C1 F1

LOI 28%

EN 1149-3

EN 13034

843

Aramid HV - 34% polyester / 25% viscose / 24% aramid / 13% modacrylic / 3% polyamide / 1% antistatic, 270 g/m²

Inherent Flame Retardant fabric in fluorescent colours.

EN ISO 11612 A1 B1 C1 F1

EN 11611 class 1

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 8,1 cal/cm²

EN 1149-3

EN 13034

EN ISO 20471

845

Aramid 6.4FC - 79% aramid / 20% modacrylic / 1% antistatic, 220 g/m²

Inherent Flame Retardant fabric with good Flame Retardant properties, combined with high durability and low weight.

EN ISO 11612 A1+A2 B1 C1 F1

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 10,1 cal/cm²

LOI 31,2%

EN 1149-3

EN 13034

846

Ara TX - 36% modacrylic / 33% polyester / 30% aramid / 1% antistatic, 260 g/m²

Inherent Flame Retardant, fabric in fluorescent colour.

EN ISO 11612 A1 B1 C1 F1

EN ISO 11611 class 1

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 8,4 cal/cm²

LOI 30,1%

EN 1149-3

EN 13034

EN ISO 20471

850

Denim Stretch 1.0 - 57% modacrylic / 37% cotton / 5% elastic fibre / 1% antistatic, 345 g/m²

Inherent Flame Retardant unwashed jeans fabric.

EN ISO 11612 A1 B1 C1 E2 F1

EN ISO 11611 class 1

IEC 61482-1-2 class 1

IEC 61482-1-1, EBT: 12,8 cal/cm²

LOI 29,4%

EN 1149-3

851

FR Stretch - 78% aramid / 20% elastic fibre / 2% antistatic, 300 g/m²

Inherent Flame Retardant fabric with high elasticity.

EN ISO 11612 A1+A2 B1 C1 F1

IEC 61482-1-2 class 1

EN 1149-3

862

Outback 250 - 65% viscose / 22% aramid / 12% polyamide / 1% antistatic, 250g/m²

Inherent Flame Retardant fabric with good Flame Retardant protection combined with a soft feeling and good washing properties.

EN ISO 11612 A1+A2 B1 C1 D1 E1 F1

EN ISO 11611 class 1

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 10,5 cal/cm²

LOI 28,9%

EN 1149-3

EN 13034

EN ISO 20471 for fluorescent colours

863

Outback HW – 74% viscose / 15% aramid / 10% polyamide / 1% antistatic, 425 g/m²

Inherent Flame Retardant fabric suitable for welding.

EN ISO 11612 A1+A2 B1 C1 E3 F1

EN ISO 11612 B2 C2 (863+920)

EN ISO 11611 class 2

IEC 61482-1-2 class 2

IEC 61482-1-1, ATPV: 12,3 cal/cm²

LOI 28,9%

EN 1149-3

EN 13034

873

Magma C - 55% viscose / 40% wool / 5% polyamide, 370 g/m²

Inherent Flame Retardant fabric. Comfortable wool quality suitable for aluminium industry.

EN ISO 11612 A1+A2 B1 C2 D3 E3 F1

EN ISO 11612 B2 C2 (873+901)

EN ISO 11611 class 2

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 9,5 cal/cm²

LOI 25,9%

Cryolite ISO 9185 85 g

874

Magma HV - 54% viscose / 20% wool / 20% polyamide / 5% aramid / 1% antistatic, 375 g/m²

Inherent Flame Retardant fabric. Fluorescent yellow. Suitable for aluminium industry.

EN ISO 11612 A1+A2 B1 C1 D3 E3 F1

EN ISO 11611 class 2

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 14,0 cal/cm²

LOI 33,4%

Cryolite ISO 9185 > 100g

EN ISO 20471

875

Magma S - 70% viscose / 20% wool / 10% polyamide, 310 g/m²

Inherent Flame Retardant fabric. Comfortable wool quality suitable for aluminium industry.

EN ISO 11612 A1+A2 B1 C1 D3 E3 F1

IEC 61482-1-1, ATPV: 8,3 cal/cm²

LOI 27,8%

Cryolite ISO 9185 94g

EN ISO 20471 for fluorescent colours

880

Cantex 1210 - 48% modacrylic / 46% cotton / 3% aramid / 3% antistatic, 350 g/m²

Inherent Flame Retardant fabric with good protection against molten metal, convective heat and radiant heat. Highest possible protection against molten steel.

EN ISO 11612 A1+A2 B1 C1 E3 F1 (D3: 880+920)

EN ISO 11611 class 1

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 11,9 cal/cm²

LOI 34,3%

EN 1149-3

EN 13034

882

883

Cantex 2.0 HV - 52% modacrylic / 38% cotton / 6% viscose / 3% aramid / 1% antistatic, 350 g/m²

Cantex 2.0 - 52% modacrylic / 38% cotton / 6% viscose / 3% aramid / 1% antistatic, 350 g/m²

Inherent Flame Retardant fabric with good protection against molten metal, convective heat or radiant heat. Highest possible protection against molten steel.

EN ISO 11612 A1+A2 B1 C1 E3 F1

EN ISO 11612 C2 (882/883+920)

EN ISO 11611 class 1

IEC 61482-1-2 class 1

IEC 61482-1-2 class 2 (882/883+920)

IEC 61482-1-1, ATPV: 15,0 cal/cm²

IEC 61482-1-1, ATPV: 29,9 cal/cm² (882/883+920)

IEC 61482-1-1, ATPV: 40,7 cal/cm² (882/883+911+920)

LOI 32,3%

EN 1149-3

EN 13034

EN ISO 20471 for fluorescent colours

891

Cantex Dual 220 - 35% modacrylic / 30% polyester / 21% viscose / 9% cotton / 3% polyamide / 2% antistatic, 220 g/m²

Double knitted, inherent Flame Retardant tricot with a high comfort level in fluorescent colours.

EN ISO 11612 A1 B1 C1 F1

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 7,3 cal/cm²

LOI 25,4%

EN 1149-3

EN ISO 20471

892

Cantex Dual 320 - 42% modacrylic / 21% polyester / 18% cotton / 14% viscose / 3% polyamide / 2% antistatic, 320g/m²

Double knitted, inherent Flame Retardant tricot with a high comfort level in fluorescent colours.

EN ISO 11612 A1 B1 C2 F1

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 11,3 cal/cm²

LOI 28,3%

EN 1149-3

EN ISO 20471

893

Cantex Fleece - 45% modacrylic / 35% cotton / 18% polyester / 2% antistatic, 330 g/m²

Inherent Flame Retardant fleece.

EN ISO 11612 A1+A2 B1 C2 F2

IEC 61482-1-2 class 1

EN 1149-3

894

Cantex Jersey 170AT - 54% modacrylic / 44% cotton / 2% antistatic, 170g/m²

Inherent Flame Retardant single jersey.

EN ISO 11612 A1+A2 B1 C1 F1

IEC 61482-1-2 class 1

EN 1149-3

895

Cantex Jersey AT - 59% modacrylic / 39% cotton / 2% antistatic, 190 g/m²

Inherent Flame Retardant single jersey.

EN ISO 11612 A1 B1 C1

EN 1149-3

EN ISO 20471, fluorescent colours

Article 5072 89, 6372 89 and 6375 89 also applies to the following certifications:

IEC 61482-1-2 class 1

IEC 61482-1-1, EBT: 5,1 cal/cm²

LOI 26,0%

896

Outback J245 - 79% viscose / 10% aramid / 10% polyamide / 1% antistatic, 245 g/m²

Inherent Flame Retardant single jersey with protection against Electric Arc, open arc cat.2

EN ISO 11612 A1 B1 C1 F1

IEC 61482-1-1, EBT: 8,5 cal/cm²

EN 1149-3

897

Cantex Pique - 59% modacrylic / 39% cotton / 2% antistatic, 220 g/m²

Inherent Flame Retardant pique.

EN ISO 11612 A1 B1 C1 F1

IEC 61482-1-2 class 1

IEC 61482-1-1, EBT: 6,3 cal/cm²

IEC 61482-1-1, ATPV: 20,9 cal/cm² (897+811)

LOI 26,1%

EN 1149-3

898

Cantex Jersey IR - 54% modacrylic / 44% cotton / 2% antistatic, PU-laminated, 210 g/m²

Functional and light lining in Inherent Flame Retardant fabric. Wind and water repellent laminate. Waterproof 10000 mm.

EN ISO 14116 Index 3

EN 1149-3

899

Cantex Terry - 59% modacrylic / 39% cotton / 2% antistatic, 290 g/m²

Inherent Flame Retardant sweatshirt tricot with ring spun reverse.

EN ISO 11612 A1 B1 C2 F1

IEC 61482-1-2 class 1

IEC 61482-1-1, EBT: 17,8 cal/cm²

IEC 61482-1-1, EBT: 33,5 cal/cm² (899+895)

LOI 26,5%

EN 1149-3

EN ISO 20471 for fluorescent colours

901

Merino RX - 60% wool / 38% viscose / 2% antistatic, 200 g/m²

Inherent Flame Retardant knitted rib in soft merino wool and FR viscose.

EN ISO 11612 A1+A2 B1 C1 F1

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 5,5 cal/cm²

LOI 27,7%

EN 1149-3

902

Merino BX - 60% wool / 38% viscose / 2% antistatic, 250 g/m²

Bird-Eye, inherent Flame Retardant tricot in soft merino wool and FR viscose.

EN ISO 11612 A1+A2 B1 C1 F1

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 10,9 cal/cm²

IEC 61482-1-1, ELIM: 17 cal/cm², ATPV: 25 cal/cm² (902+811)

LOI 28,5%

EN 1149-3

903

Merino TX - 60% wool / 38% viscose / 2% antistatic, 360 g/m²

Inherent Flame Retardant terry in soft merino wool and FR viscose.

EN ISO 11612 A1+A2 B1 C2 F1

IEC 61482-1-2 class 1

IEC 61482-1-1, ATPV: 12,7 cal/cm²

IEC 61482-1-1, ELIM: 26 cal/cm², ATPV: 29 cal/cm² (903+901)

IEC 61482-1-1, ELIM: 37 cal/cm², ATPV: 47 cal/cm²  (903+811+901)

LOI 28,7%

EN 1149-3

911

Cantex Pro 145 - 45% modacrylic / 35% cotton / 18% polyamide / 2% antistatic, 160 g/m²

Shirt quality in comfortable, Inherent Flame Retardant twill.

EN ISO 11612 A1 B1 C1 F1

IEC 61482-1-2 class 1

IEC 61482-1-1, ELIM: 5,0 cal/cm², ATPV: 5,8 cal/cm²

IEC 61482-1-1, ATPV: 17,0 cal/cm² (911+894)

LOI 26,7%

EN 1149-3

EN ISO 20471 for fluorescent colours

920

Cantex JX - 59% modacrylic / 39% cotton / 2% antistatic, 235 g/m²

Inherent Flame Retardant channel stitched tricot.

EN ISO 11612 A1 B1 C1 F1

IEC 61482-1-2 class 1

IEC 61482-1-1, EBT: 7,0 cal/cm²

LOI 30,1%

EN 1149-3

922

Cantex JL - 57% modacrylic / 36% cotton / 5% elastane / 2% antistatic, 240 g/m²

Inherent Flame Retardant single jersey with elastane.

EN ISO 14116 Index 3

EN 1149-3

931

Cantex 240IR - 54% modacrylic / 44% cotton / 2% antistatic, PU-laminated, 260 g/m²

Inherent Flame Retardant twill with PU laminate.

Wind and waterproof according to EN 343 3:4. Waterproof 10 000 mm.

Breathability / water vapor resistance 9.5 Pa m²/W.

EN ISO 11612 A1+A2 B1 C1 E2 F1

EN ISO 11611 class 1

IEC 61482-1-2 class 2 (931+911)

IEC 61482-1-1, ATPV: 40,1 cal/cm² (931+055)

EN 13034

EN 1149-3

EN ISO 20471 for fluorescent colours

EN 343 class 3:4

942

MegaTX 235 - 42% viscose / 26% modacrylic / 20% cotton / 5% aramid / 5% polyamide / 2% antistatic, 235 g/m²

Inherent Flame Retardant shirt fabric.

EN ISO 11612 A1 B1 C1 F1

EN ISO 11611 class 1

IEC 61482-1-1, ATPV: 8,8 cal/cm²

LOI 26,7%

EN 1149-3

943

Mega TX 230IR - 40% modacrylic / 37% FR viscose / 22% viscose / 1% antistatic, PU-laminated, 230 g/m²

Inherent Flame Retardant fabric with PU laminate.

Wind and waterproof according to EN 343 3:4. Waterproof 8 000 mm.

Breathability / water vapor resistance 8.3 Pa m²/W.

EN ISO 11612 A1+A2 B1 C1 F1

EN ISO 11611 class 1

IEC 61482-1-2 class 1

IEC 61482-1-2 class 2 (943+805/911)

IEC 61482-1-1, ATPV: 21,3 cal/cm² (943+805)

IEC 61482-1-1, ATPV: 23,8 cal/cm² (943+911)

IEC 61482-1-1, ELIM: 43 cal/cm², ATPV: 48 cal/cm² (943+899+901)

LOI 25,5%

EN 13034

EN 1149-3

EN ISO 20471 for fluorescent colour

EN 343 class 3:4

950

Windtech FR 340 - 54% modacrylic / 42% cotton / 2% polyamide / 1% elastic fibre / 1% antistatic, PU-laminated, 340 g/m²

Inherent Flame Retardant softshell.

Wind and water repellent. Waterproof 10 000 mm.

Breathability / water vapor resistance 22.0 Pa m²/W.

EN ISO 11612 A1 B1 C1 F1

EN ISO 11611 class 2

IEC 61482-1-2 class 2

IEC 61482-1-1, ELIM: 23,0 cal/cm², EBT: 28,0 cal/cm²

LOI 29,5%

EN 1149-3

EN 13034

EN ISO 20471 for fluorescent colour

951

Windtech FR HVO - 45% modacrylic / 36% cotton / 18% polyester / 1% antistatic, PU-laminated, 385 g/m²

Inherent Flame Retardant softshell.

Wind and water repellent. Waterproof 10 000 mm.

EN ISO 11612 A1 B1 C2 F2

IEC 61482-1-2 class 2

IEC 61482-1-1, ELIM: 12,0 cal/cm², ATPV: 19,0 cal/cm²

EN 1149-3

EN 13034

EN ISO 20471

RIS-3279-TOM fluorescent orange certified for UK railways
